MLP.038007LCD Polarizing Microscope, 9.7'' LCD, 5M, 40~600X, Transmitetd Illumination
  • /usr/575/images/Products/Y/57520177.jpg
  •
  •
  •
  • LCD Polarizing Microscope
  • 9.7’’ LCD Screen,resolution 1024*768
  • 5.0M CMOS Image Sensor built-in
  • Infinity independent achromatic optical system,40X~600X
  • Transmitetd Illumination
9.7" LCD Pad with Andriod System of MLP.038007
Specification of LCD PAD
 LCD Screen 9.7" HD Diagonal IPS LCD
Resolution 1024*768
Backlight Screen,
Five Point Touch Screen,
Hardware Power Switch
CPU

1.6GHz Four Core ARM Mali-400 MP GPU
Support OpenGL ES 1.1/2.0 And OpenVG 1.1
Support Full HD 1080p
Support Android 4.2 System
RAM 2GB, Support DDR3, DDR2, LPDDR2
Data Storage SD Card Slot, Support Max 32GB C10 High Speed SD Card
Data Interface HDMI, Mini USB2.0, USB 2.0
Operation System Android 4.2 System, Multi Language
Power Wide Voltage AC 100~240V, DC 5V/2A with External Power Adaptor,
Power Mode : Normal, Sleep, Power Off
WIFI Support
Bluetooth Support
Software YX Camera Installed,
--Can Adjust Real Time Image
--Can Measure Length, Area, Angle, Count
--Can Take Picture, Record Video
YX Image Installed
--Grey, Contrast, Brightness Adjust
--Binary Image For Granular Count
Both Software Chinese/English Version, With Instruction Manual Installed
Product Size Pad 17.5*22.5*2.0cm
Package Size Packing Box 10*24*29cm, 1 pc/Box
Specification of Digital Camera Senser

1/2.5" CMOS, Color, Aptina MT9P001
Resolution
 5.0M Pixels, Maximum Photo Resolution 2592*1944
Pixel Size 2.2um*2.2 um
Effective Image Size 5.70(H) * 4.28(V)mm, (7.23mm Diagonal)
Frame Rate 1280*720/15 Fps, 640*480/30Fps
Dynamic Range 66.5dB
SNR 40.5dB Max
ADC 12 Bit, On Chip
Shutter Type ERS, Auto
White Balance Auto
Connect Standard C-Mount Interface

Specification of Main Body
Specification
Main Body of MLP.038007
Magnification 40x - 600x
Optical System UCIS infinity independent achromatic optical system
Head
Seidentopf trinocular head 30° inclined, rotatable 360°,interpupillary distance 52-75mm
Eyepiece
 Plan WF10x/20mm, high eyepoint up to 21mm,
Plan WF10x/20mm, polarizing reticule eyepiece
Objective
 Infinity strain-free achromatic objectives 4X
Infinity strain-free achromatic objectives 10X
Infinity strain-free achromatic objectives 40X
Infinity strain-free achromatic objectives 60X
Nosepiece Quadruple, reversed type with positive click stops
Focusing Low positioned, coaxial coarse&fine focusing system with an adjustable tension control and upper limit stop, coarse 14mm/rot,fine 0.1mm/rot, minimum reading 1μm on left-side fine knob, moving range 20mm
Stage
Specimen holder
Rotating stage, size 142mm, pre-centered and 360° rotatable
Condenser
 Swing-Out Condenser N.A.1.25
Polarization
 The polarizer mounted under the condenser holder rotates 360° with click stops every 45°, scale 0°45°90°135°180°225°270°315°
The Intermediate tube has a analyzer with large rotation control dial for easy adjustment and accurate reading through rotations of 180°,division 1°,accuracy 6'. The built-in focusable and centerable Bertrand lens allows conoscopic observation. with compensator slot
Compensator Quartz wedge plate, I-IV class
λ Plate, first class red
1/4λ Plate
Filter Blue Φ38
Adapter 0.5x, C-Mount
Kohler Illumination with field diaphragm
Transmitetd Illumination 6V20W Halogen lamp, 110-240V wide voltage
6V20W halogen bulb (Osram)
250x/3.15A Φ5x20 fuse
Other Immersion Oil
Φ2mm Allen Screw Driver
Φ1.5mm Allen Screw Driver
Dust cover
Power cord
