MLZ.008001Zoom Lens, 0.7X~4.5X, WD=90mm, C-Mount
  • /usr/575/images/Products/Y/57519115.jpg
  • /usr/575/Picture/Y/11563.jpg
  •
  •
  • Used for machine vision, scientific research, etc.
  • Providing high resolution and high quality image.
  • Various adapter and auxiliary Lens for optional.
Specification
MLZ.008001
Magnification 0.7X~4.5X
Zoom Ratio
1:6.5
Working Distance
90mm
Focus Adjustable 0~3mm
Interface
C-Mount
Matching CCD Sensor
1/3" 1/2" 2/3"
FNO 14.4
Distortion 0.15%

Item
Optional Accessories
CCD Adapter 0.5X
0.67X
1.0X
2.0X
Auxiliary Lens
0.25X
0.5X
0.75X
1.0X
1.5X
2.0X

Adapter and Auxiliary Lens Combination Ratio Table
Auxiliary Lens
WD (mm)
CCD Sensor size
Adapter 0.5X
Adapter 0.67X
Adapter 1X
Adapter 2X



0.09X-0.56X
0.12X-0.75X
0.18X-1.13X
0.35X-2.25X
0.25X
302
1/3"
68.57-10.66
51.17-7.96
34.28-5.33
17.14-2.66

302
1/2"


45.71-7.11
22.85-3.55

302
2/3"


62.85-9.77
31.42-4.88







0.5X


0.18X-1.12X
0.23X-1.50X
0.35X-2.25X
0.7X-4.5X

176
1/3"
34.28-5.33
25.58-3.98
17.14-2.66
8.57-1.33

176
1/2"


22.85-3.55
11.42-1.77

176
2/3"


31.42-4.881
15.71-2.44







0.75X


0.26X-1.69X
0.35X-2.26X
0.53X-3.38X
1.05X-6.75X

117
1/3"
22.88-3.55
17.06-2.65
11.43-1.78
5.71-0.89

117
1/2"


15.24-2.37
7.61-1.18

117
2/3"


20.95-3.26
10.48-1.63







None


0.35X-2.25X
0.47X-3.00X
0.7X-4.5X
1.40X-9.00X

96
1/3"
17.14-2.66
12 79-1.99
8.57-1.33
4.28-0.66

96
1/2"


11.42-1.77
5.71-0.89

96
2/3"


15.71-2.44
7.86-1.22







1.5X


0.56X-3.38X
0.82X-4.52X
1.05X-6.75X
2.1X-13.5X

50
1/3"
10.67-1.78
7.31-1.33
5.71-0.86
2.86-0.89

50
1/2"


7.61-1.18
3.81-1.19

50
2/3"


10.48-1.63
5.24-1.63







2X


0.70X-4.50X
0 94X-6.03X
1.40X-9.00X
2.80X-18.00X

35
1/3"
8.57-1.33
6.40-0.99
4.28-0.66
2.14-0.33

35
1/2"


5.71-0.89
2.86-0.44

35
2/3"


7.86-1.22
3.93-0.61
